Compare GARMIN GPSMAP 64, 65, 66 & 67 Series GPS

Garmin GPSMAP handheld navigators are excellent outdoor GPS for hiking, cycling, geocaching or climbing.You are free to explore more with Garmin handheld navigation in the palm of your hand.

Here's how the Garmin GPSMAP 60 series models are different and how to find the GPSMAP 64, 65, 66 or 67 that’s best for your next outdoor adventure.

Key Differences between the Garmin GPSMAP 64, 65, 66 & 67 Series

We'll look at each GPSMAP unit below but first let's look at the key differences between the GPSMAP 64, 65, 66 & 67 series.

Garmin GPSMAP 64, 65, 66 & 67 Model Differences

• Garmin GPSMAP 66i & 67i – Send & Receive Text Messages, Share Location & Trigger SOS
• GPSMAP x, t & i Models – All have preloaded topo maps
• GPSMAP 65 & 67 Series – Routable TopoActive North America maps, Expanded GNSS Support
• GPSMAP 64, 64x & 65 – Do not have an electronic compass or barometric altimeter

Comparison of GPSMAP 64, 65, 66 & 67 Specifications & Features

Product	GPSMAP 67	GPSMAP 67i	GPSMAP 66i	GPSMAP 66s	GPSMAP 64x	GPSMAP 65	GPSMAP 65s
General
Unit dimensions	2.5” x 6.4” x 1.4” (6.2 x 16.3 x 3.5 cm)	2.5” x 6.4” x 1.4” (6.2 x 16.3 x 3.5 cm)	2.6” x 6.4” x 1.4” (6.6 x 16.3 x 3.5 cm)	2.5″ x 6.4″ x 1.4″ (6.2 x 16.3 x 3.5 cm)	2.5″ x 6.4″ x 1.4″ (6.2 x 16.3 x 3.5 cm)	2.5″ x 6.4″ x 1.4″ (6.2 x 16.3 x 3.5 cm)	2.5″ x 6.4″ x 1.4″ (6.2 x 16.3 x 3.5 cm)
Display dimensions	1.5″W x 2.5″H (3.8 x 6.3 cm); 3″ diag (7.6 cm)	1.5″W x 2.5″H (3.8 x 6.3 cm); 3″ diag (7.6 cm)	1.5″W x 2.5″H (3.8 x 6.3 cm); 3″ diag (7.6 cm)	1.5″W x 2.5″H (3.8 x 6.3 cm); 3″ diag (7.6 cm)	1.43″ x 2.15″ (3.6 x 5.5 cm); 2.6″ diag (6.6 cm)	1.43″ x 2.15″ (3.6 x 5.5 cm); 2.6″ diag (6.6 cm)	1.43″ x 2.15″ (3.6 x 5.5 cm); 2.6″ diag (6.6 cm)
Display resolution	240 x 400 pixels	240 x 400 pixels	240 x 400 pixels	240 x 400 pixels	160 x 240 pixels	160 x 240 pixels	160 x 240 pixels
Display type	transflective color TFT	transflective color TFT	transflective color TFT	transflective color TFT	transflective, 65-K color TFT	transflective, 65-K color TFT	transflective, 65-K color TFT
Weight w/ batteries	8.1 oz (230 g)	8.1 oz (230 g)	8.5 oz (241 g)	8.1 oz (230 g)	7.7 oz (217 g) with batteries	7.7 oz (217 g) with batteries	7.7 oz (217 g) with batteries
Battery	rechargeable, internal lithium-ion	rechargeable, internal lithium-ion	rechargeable, internal lithium-ion	2 AA batteries (not included); NiMH or Lithium recommended	2 AA batteries (not included); NiMH or Lithium recommended	2 AA batteries (not included); NiMH or Lithium recommended	2 AA batteries (not included); NiMH or Lithium recommended
Battery Life	Up to 180 hours in default mode Up to 840 hours in expedition mode	Up to 165 hours with inReach® enabled with 10 minute tracking Up to 180 hours in GPS Mode Up to 425 hours in Expedition mode with inReach enabled Up to 840 hours in Expedition mode	up to 35 hours at 10-minute tracking; up to 200 hours at 30-minute tracking (power save mode)	Up to 16 hours (Standard mode) Up to 1 week (Expedition mode)	16 hours	16 hours	16 hours
Waterproof	✅ (IPX 7)	✅ (IPX 7)	✅ (IPX 7)	✅ (IPX 7)	✅ (IPX 7)	✅ (IPX 7)	✅ (IPX 7)
Interface	USB-C	USB-C	high-speed USB and NMEA 0183 compatible	high-speed USB and NMEA 0183 compatible	USB and NMEA 0183 compatible	high-speed USB and NMEA 0183 compatible	high-speed USB and NMEA 0183 compatible
MIL STD 810G ruggedness for thermal, shock and water performance	✅	✅	✅	✅	❌	❌	❌
RINEX logging	✅	✅	✅	✅	❌	❌	❌
LED beacon flashlight	✅	✅	✅	✅	❌	❌	❌
Built-in memory	(user space varies based on included mapping)	(user space varies based on included mapping)	16 GB	16 GB	8 GB (user space varies based on included mapping)	16 GB	16 GB
Maps & Memory
Basemap	✅	✅	✅	✅	✅	✅	✅
Preloaded maps	✅(TopoActive, routable)	✅(TopoActive, routable)	✅ (TopoActive U.S and Canada; routable)	❌	✅ (TopoActive U.S and Canada; routable)	✅ (TopoActive U.S and Canada; routable)	✅ (TopoActive U.S and Canada; routable)
Ability to add maps	✅	✅	✅	✅	✅	✅	✅
Federal public land boundaries	❌	❌	❌	❌	❌	✅	✅
Accepts data cards	✅ (32 GB max microSD™ card)	✅(32 GB max microSD™ card)	✅	✅	✅ (32 GB max microSD™ card)	✅ (32 GB max microSD™ card)	✅ (32 GB max microSD™ card)
Waypoints	10,000	10,000	10,000	10,000	5,000	5,000	5,000
Courses	250, 200 course points per course	250, 200 course points per course	250, 200 course points per course	250, 200 course points per course	❌	❌	❌
Tracks	250	250	250	250	200	200	200
Navigation Track Log	20,000 points, 250 saved gpx tracks, 300 saved fit activities	20,000 points, 250 saved gpx tracks, 300 saved fit activities	20,000 points, 250 saved gpx tracks, 300 saved fit activities	20,000 points, 250 saved gpx tracks, 300 saved fit activities	10,000 points, 200 saved tracks	10,000 points, 200 saved tracks	10,000 points, 200 saved tracks
Map segments	15,000	15,000	15,000	15,000	3,000	3,000	3,000
Satellite Imagery	✅ (direct to device)	✅ (direct to device)	✅ (direct to device)	✅ (direct to device)	❌	❌	❌
Includes detailed hydrographic features (coastlines, lake/river shorelines, wetlands and perennial and seasonal streams)	✅	✅	✅	✅	✅	✅	✅
Includes searchable points of interests (parks, campgrounds, scenic lookouts and picnic sites)	✅	✅	✅	✅	✅	✅	✅
Displays national, state and local parks, forests, and wilderness areas	✅	✅	✅	✅	✅	✅	✅
Activities	✅	✅	✅	✅	❌	❌	❌
Navigation Routes	250, 250 points per route; 50 points auto routing	250, 250 points per route; 50 points auto routing	250	250, 250 points per route; 50 points auto routing	200, 250 points per route; 50 points auto routing	200, 250 points per route; 50 points auto routing	200, 250 points per route; 50 points auto routing
Automatic Routing	✅	✅	✅	✅ (with optional mapping for detailed roads)	✅	✅	✅
Sensors
High-sensitivity receiver	✅ GPS, GLONASS, Galileo, QZSS, BeiDou and IRNSS	✅ GPS, Galileo, QZSS, BeiDou and IRNSS	✅ Galileo, GLONASS & GPS	✅ Galileo, GLONASS & GPS	✅ Galileo, GLONASS & GPS	✅ GPS, GLONASS, Galileo, QZSS and IRNSS	✅ GPS, GLONASS, Galileo, QZSS and IRNSS
Multi-band frequency support	✅	✅	❌	❌	❌	✅	✅
Bluetooth/ANT+/WiFi	Bluetooth, ANT+ and WiFi	Bluetooth, ANT+ and WiFi	Bluetooth, ANT+ and WiFi	Bluetooth, ANT+ and WiFi	❌	Bluetooth and ANT+	Bluetooth and ANT+
Electronic Compass	✅ (tilt-compensated, 3-axis)	✅ (tilt-compensated, 3-axis)	✅ (tilt-compensated, 3-axis)	✅ (tilt-compensated, 3-axis)	❌	❌	✅ (tilt-compensated, 3-axis)
Barometric altimeter	✅	✅	✅	✅	❌	❌	✅
Outdoor Recreation
Point-to-point navigation	✅	✅	✅	✅	✅	✅	✅
TracBack®	✅	✅	✅	✅	❌	❌	❌
Picture viewer	✅	✅	✅	✅	✅	✅	✅
Custom map compatible	✅ (500 custom map tiles)	✅ (500 custom map tiles)	✅ (500 custom map tiles)	✅ (500 custom map tiles)	✅ (500 custom map tiles)	✅ (500 custom map tiles)	✅ (500 custom map tiles)
BirdsEye satellite Imagery Compatible	BirdsEye Direct to device (no annual subscription required)	BirdsEye Direct to device (no annual subscription required)	BirdsEye Direct to device (no annual subscription required)	BirdsEye Direct to device (no annual subscription required)	❌	❌	❌
Geocaching-friendly	✅ (Geocaching Live)	✅ (Geocaching Live)	✅ (Geocaching Live)	✅ (Geocaching Live)	✅ (Paperless)	✅ (Paperless)	✅ (Paperless)
Hunt/Fish calendar	✅	✅	✅	✅	✅	✅	✅
Sun and moon information	✅	✅	✅	✅	✅	✅	✅
Area calculations	✅	✅	✅	✅	✅	✅	✅
Custom POIs	✅	✅	✅	✅	✅	✅	✅
Xero Locations	✅	✅	✅	✅	❌	❌	❌
Daily Smart Features
Smart Notifications	✅	✅	✅	✅	❌	✅	✅
Live Tracking	✅	✅	✅	✅	❌	❌	❌
Garmin Connect compatible	✅	✅	✅	✅	✅	✅	✅
Garmin Explore compatible	✅	✅	✅	✅	❌	✅	✅
Garmin connect IQ compatible	✅	✅	✅	✅	❌	❌	❌
Compatible with Garmin Messenger app	❌	✅	❌	❌	❌	❌	❌
Smart switching between Wi-Fi, Cellular and Satellite with Garmin Messenger app	❌	✅	❌	❌	❌	❌	❌
inReach remote widget	❌	built in inReach capabilities	built in inReach capabilities	✅	❌	❌	❌
inReach Features
Interactive SOS	❌	✅	✅	❌	❌	❌	❌
inReach weather	❌	✅	✅	❌	❌	❌	❌
Send and receive text messages to SMS and email	❌	✅	✅	❌	❌	❌	❌
Send and receive text messages to other inReach device	❌	✅	✅	❌	❌	❌	❌
Send and receive group messages	❌	✅	✅	❌	❌	❌	❌
Exchange locations with other inReach device	❌	✅	✅	❌	❌	❌	❌
Wikiloc (Preloaded with the Wikiloc app with risk-free trial offering more than 9 million trails for download)	❌	❌	✅	❌	❌	❌	❌
MapShare compatible with tracking	❌	✅	✅	❌	❌	❌	❌
Virtual keyboard for custom messaging	❌	✅	✅	❌	❌	❌	❌
Send waypoints to MapShare during trip	❌	✅	✅	❌	❌	❌	❌
Send route selection to MapShare during trip	❌	✅	✅	❌	❌	❌	❌
inReach remote compatible	✅	❌	❌	❌	❌	❌	❌

Garmin GPSMAP 64, 65, 66 & 67 FAQs

I like the 66sr but the internal battery worries me. What gps is equivalent with replaceable batteries without losing water proof features and shock resistance ?

The closest unit to the 66SR that would take AA batteries would be the Garmin GPSMAP 65S this unit will have the advanced GPS receiver and the capabilities of doing GNSS.
