Yaesu FTDX 10 Specifications |
|
|
Frequency Ranges |
RX 30kHz – 75MHz (Operating) 1.8MHz – 29.699999MHz (Specified performance, Amateur bands only)* *5.1675/5.332/5.348/5.3585/5.373/5.405MHz (US only), 5.351500-5.366500MHz (EU only)/ 5.25000-5.406500 (UK only) 50MHz – 53.999999MHz (Specified performance, Amateur bands only) 70MHz – 70.499999MHz (Specifed performance, UK Amateur bands version only) TX 1.8 – 54MHz (Amateur bands only) |
|
Modulation Type |
A1A(CW), A3E(AM), J3E(LSB,USB), F3E(FM),F1B(RTTY),G1B(PSK) |
|
Frequency Stability |
±0.5ppm (32°F to +122°F/0°C to +50°C, after 1min) |
|
Supply Voltage |
DC 13.8V ±15% |
|
Circuit Type |
Double-Conversion Super heterodyne |
|
Intermediate Frequencies |
1st IF 9.005MHz 2nd IF 24kHz |
|
RF Power Output |
5W – 100W (CW, LSB, USB, FM, RTTY, PKT) 5W - 25W (AM) |
|
Case Size(W x H x D) |
10.47 x 3.58 x 10.35(inch) / 266 x 91 x 263 (mm) |
|
Weight (Approx.) |
13lbs/ 5.9kg |
